AirComp

Behind

Brand

Modular configuration
Deliver 20 Nl/min of compressed air from a full oil free compressor at 8 bar
Able to feed up to 2 Brezza units
Highly compact and provided with all the control devices
Very silent; Noise levels reduced to minimum by a special soundproofing and anti-vibrations measures
Optional CPU for remote control CAN-BUS, up to32 units

Specifications

Downloads

FLOW RATE	20 Nl/min ± 2 Nl/min up to 2000 m from the sea
TECHNOLOGIES EMPLOYED	Oil free piston compressor
OUTPUT PRESSURE	0÷8 bar ± 3% (± 240 mbar)
AIR OUTPUT CHARACTERISTICS	Particulate = 0,01 mm Moisture = -15° C dew point ATP
ELECTRICAL SUPPLY	220 Vac ±10% 50 Hz 550 VA
INDEX OF PROTECTION	IP20
NOISE	< 55 dBA
OPERATING TEMPERATURE	5°C - 40°C/40°F - 100°F
ENVIRONMENTAL HUMIDITY	max 90% without condensation
DIMENSIONS	Height: 40 cm + 7 cm (base) /15.8” + 2.8” Width: 38 cm/14.9” Depth: 53 cm/20.8”
WEIGHT	25 kg/55 lbs
PNEUMATIC CONNECTIONS	Purified air output: G 1/8” female

Catálogo AirComp

Choose your product

Filters Clear Filters

Reference CL-422.04.0130

Description Compresor Air Comp
