Halo UHPLC Columns

High Speed Separations

  • Smaller reduced plate heights lead to high efficiencies; narrower and taller peaks, for improved resolution and lower detection limits (LODs and LOQs)
  • Flat van Deemter plot and higher linear velocity optimum allow higher flow rates with minimal column efficiency loss

High Resolution Separations

  • High efficiency with longer geometries (100, 150, 250 mm) provides greater resolving power for challenging applications
  • Lower back pressure permits columns to be used in series for the most demanding UHPLC and HPLC separations

Excellent Ruggedness and Reproducibility

  • Less plugging, longer usable column lifetime and greater uptime due to larger porosity frits (vs. sub-2 µm totally porous (non-core) columns)
    • 2 µm frits for HALO 2.7 and HALO 5
    • 1 µm frits for HALO 2 vs. 0.2–0.5 µm frits for sub-2 µm non-core columns
  • Excellent column-to-column and lot-to-lot reproducibility
HALO Fused-Core Performance
Fused-Core silica particles
Performance vs. non-core Columns
Applications
Downloads

HALO Fused-Core Performance

High Speed Separations

  • Smaller reduced plate heights lead to high efficiencies; narrower and taller peaks, for improved resolution and lower detection limits (LODs and LOQs)
  • Flat van Deemter plot and higher linear velocity optimum allow higher flow rates with minimal column efficiency loss

High Resolution Separations

  • High efficiency with longer geometries (100, 150, 250 mm)
    provides greater resolving power for challenging applications
  • Lower back pressure permits columns to be used in series for the most demanding UHPLC and HPLC separations

Excellent Ruggedness and Reproducibility

  • Less plugging, longer usable column lifetime and greater uptime due to larger porosity frits (vs. sub-2 µm totally porous (non-core) columns)
    • 2 µm frits for HALO 2.7 and HALO 5
    • 1 µm frits for HALO 2 vs. 0.2–0.5 µm frits for sub-2 µm non-core columns
  • Excellent column-to-column and lot-to-lot reproducibility
Tecnología Fused Core
de sílice de HALO Protein 1000Å 2,7 µm
Scanning Electron Microscope (SEM) image of HALO 2 particles. The particle size distribution is very narrow due to the separate sizing steps for solid cores and finished Fused-Core silica particles.
SEM image of a focused-ion-beam-cleaved HALO Protein 1000Å 2.7 µm silica particle. This “cut-away” view shows the solid core with its outer porous layer.

Van Deemter Plot of Plate Height vs. Linear Velocity (flow rate)

Van Deemter Plot of Plate Height vs. Linear Velocity (flow rate)

UltraFast Peptide Separation

UltraFast Peptide Separation

Ultrafast Ballistic Gradient using HALO 5

Ultrafast Ballistic Gradient using HALO 5

Carbonyl-DNPH High Resolution Separation

Carbonyl-DNPH High Resolution Separation

Choose your product
showing 20 of 1074 products
Technology
Hilic (228)
Normal Phase/Reverse Phase (114)
Reverse Phase (732)
Support
Fused Core Silica (1074)
Brand
Halo 2 (144)
Halo 2.7 (480)
Halo 5 (450)
Function
AQ C18 (114)
Biphenyl (48)
C18 (114)
C8 (114)
ES-CN (114)
HILIC (114)
Penta-HILIC (114)
PFP (114)
Phenyl-Hexyl (114)
RP-Amide (114)
Type
Analytical (152)
Capillary (285)
Microbore (552)
Semipreparative (85)
Pore Size
90 Å (1074)
Particle Size
2 µm (144)
2,7 µm (480)
5 µm (450)
Length
100 mm (208)
150 mm (208)
20 mm (75)
250 mm (93)
30 mm (94)
5 mm (75)
50 mm (208)
75 mm (113)
Column ID
0,075 mm (57)
0,10 mm (57)
0,20 mm (57)
0,30 mm (57)
0,50 mm (57)
1,0 mm (104)
10 mm (85)
2,1 mm (224)
3,0 mm (224)
4,6 mm (152)
Reference HAL-91812-101
Description HALO 90 A HILIC, 2 um, 2.1 x  5 mm, Guard Column 3pk
Price 451,50€
Quantity
To be able to buy you must be registered Sign up
To use the Favorites List you must be registered Sign up
Reference HAL-91812-102
Description HALO 90 A C18, 2 um, 2.1 x 5  mm, Guard Column 3pk
Price 451,50€
Quantity
To be able to buy you must be registered Sign up
To use the Favorites List you must be registered Sign up
Reference HAL-91812-104
Description HALO 90 A ES-CN, 2 um, 2.1 x  5 mm, Guard Column 3pk
Price 451,50€
Quantity
To be able to buy you must be registered Sign up
To use the Favorites List you must be registered Sign up
Reference HAL-91812-105
Description HALO 90 A Penta-HILIC, 2 um,  2.1 x 5 mm, Guard Column 3pk
Price 451,50€
Quantity
To be able to buy you must be registered Sign up
To use the Favorites List you must be registered Sign up
Reference HAL-91812-106
Description HALO 90 A Phenyl-Hexyl, 2 um , 2.1 x 5 mm, Guard Column 3pk
Price 451,50€
Quantity
To be able to buy you must be registered Sign up
To use the Favorites List you must be registered Sign up
Reference HAL-91812-107
Description HALO 90 A RP-Amide, 2 um, 2. 1 x 5 mm, Guard Column 3pk
Price 451,50€
Quantity
To be able to buy you must be registered Sign up
To use the Favorites List you must be registered Sign up
Reference HAL-91812-108
Description HALO 90 A C8, A um, 2.1 A 5 mm, Guard Column 3pk
Price 0,00€
Quantity
To be able to buy you must be registered Sign up
To use the Favorites List you must be registered Sign up
Reference HAL-91812-109
Description HALO 90 A PFP, 2 um, 2.1 x 5  mm, Guard Column 3pk
Price 451,50€
Quantity
To be able to buy you must be registered Sign up
To use the Favorites List you must be registered Sign up
Reference HAL-91812-122
Description HALO 90 A AQ-C18, 2 um, 2.1  x 5 mm, Guard Column 3pk
Price 451,50€
Quantity
To be able to buy you must be registered Sign up
To use the Favorites List you must be registered Sign up
Reference HAL-91812-201
Description HALO 90 A HILIC, 2 um, 2.1 x  20 mm
Price 609,00€
Quantity
To be able to buy you must be registered Sign up
To use the Favorites List you must be registered Sign up
Reference HAL-91812-202
Description HALO 90 A C18, 2 um, 2.1 x 2 0 mm
Price 609,00€
Quantity
To be able to buy you must be registered Sign up
To use the Favorites List you must be registered Sign up
Reference HAL-91812-204
Description HALO 90 A ES-CN, 2 um, 2.1 x  20 mm
Price 609,00€
Quantity
To be able to buy you must be registered Sign up
To use the Favorites List you must be registered Sign up
Reference HAL-91812-205
Description HALO 90 A Penta-HILIC, 2 um,  2.1 x 20 mm
Price 609,00€
Quantity
To be able to buy you must be registered Sign up
To use the Favorites List you must be registered Sign up
Reference HAL-91812-206
Description HALO 90 A Phenyl-Hexyl, 2 um , 2.1 x 20 mm
Price 609,00€
Quantity
To be able to buy you must be registered Sign up
To use the Favorites List you must be registered Sign up
Reference HAL-91812-207
Description HALO 90 A RP-Amide, 2 um, 2. 1 x 20 mm
Price 609,00€
Quantity
To be able to buy you must be registered Sign up
To use the Favorites List you must be registered Sign up
Reference HAL-91812-208
Description HALO 90 A C8, 2 um, 2.1 x 20  mm
Price 609,00€
Quantity
To be able to buy you must be registered Sign up
To use the Favorites List you must be registered Sign up
Reference HAL-91812-209
Description HALO 90 A PFP, 2 um, 2.1 x 2 0 mm
Price 609,00€
Quantity
To be able to buy you must be registered Sign up
To use the Favorites List you must be registered Sign up
Reference HAL-91812-222
Description HALO 90 A AQ-C18, 2 um, 2.1  x 20 mm
Price 609,00€
Quantity
To be able to buy you must be registered Sign up
To use the Favorites List you must be registered Sign up
Reference HAL-91812-301
Description HALO 90 A HILIC, 2 um, 2.1 x  30 mm
Price 609,00€
Quantity
To be able to buy you must be registered Sign up
To use the Favorites List you must be registered Sign up
Reference HAL-91812-302
Description HALO 90 A C18, 2 um, 2.1 x 3 0 mm
Price 609,00€
Quantity
To be able to buy you must be registered Sign up
To use the Favorites List you must be registered Sign up
showing 20 of 1074 products
